國產SiC碳化硅MOSFET功率器件可靠性及一致性如何確保？

電力電子系統研發制造商一般需要碳化硅MOSFET功率器件供應商提供可靠性測試報告的原始數據和器件封裝的FT數據。

SiC碳化硅MOSFET可靠性報告原始數據主要來自以下可靠性測試環節的測試前后的數據對比，通過對齊可靠性報告原始數據測試前后漂移量的對比，從而反映器件的可靠性控制標準及真實的可靠性裕量。SiC碳化硅MOSFET可靠性報告原始數據主要包括以下數據:

SiC碳化硅MOSFET高溫反偏High Temperature Reverse Bias HTRB Tj=175℃VDS=100%BV

SiC碳化硅MOSFET高溫柵偏（正壓）High Temperature Gate Bias（+） HTGB（+） Tj=175℃VGS=22V

SiC碳化硅MOSFET高溫柵偏（負壓）High Temperature Gate Bias（-） HTGB（-） Tj=175℃VGS=-8V

SiC碳化硅MOSFET高壓高濕高溫反偏High Voltage, High Humidity, High Temp. Reverse Bias HV-H3TRB Ta=85℃RH=85%VDS=80%BV

SiC碳化硅MOSFET高壓蒸煮Autoclave AC Ta=121℃RH=100%15psig

SiC碳化硅MOSFET溫度循環Temperature Cycling TC -55℃ to 150℃

SiC碳化硅MOSFET間歇工作壽命Intermittent Operational Life IOL △Tj≥100℃Ton=2minToff=2min

FT數據來自碳化硅MOSFET功率器件FT測試(Final Test，也稱為FT)是對已制造完成的碳化硅MOSFET功率器件進行結構及電氣功能確認，以保證碳化硅MOSFET功率器件符合系統的需求。

通過分析碳化硅MOSFET功率器件FT數據的關鍵數據（比如V(BR)DSS，VGS(th)，RDS(on)，

IDSS）的正態分布，可以定性碳化硅MOSFET功率器件材料及制程的穩定性，這些數據的定性對電力電子系統設計及大批量制造的穩定性也非常關鍵。



基本™（BASiC Semiconductor）第二代SiC碳化硅MOSFET兩大主要特色：



1.出類拔萃的可靠性：相對競品較為充足的設計余量來確保大規模制造時的器件可靠性。

基本™（BASiC Semiconductor）第二代SiC碳化硅MOSFET 1200V系列擊穿電壓BV值實測在1700V左右，高于市面主流競品，擊穿電壓BV設計余量可以抵御碳化硅襯底外延材料及晶圓流片制程的擺動，能夠確保大批量制造時的器件可靠性，這是基本™（BASiC Semiconductor）第二代SiC碳化硅MOSFET布袋除塵器關鍵的品質. 基本™（BASiC Semiconductor）第二代SiC碳化硅MOSFET雪崩耐量裕量相對較高，也增強了在電力電子系統應用中的可靠性。



2.可圈可點的器件性能：同規格較小的Crss帶來出色的開關性能。

基本™（BASiC Semiconductor）第二代SiC碳化硅MOSFET反向傳輸電容Crss 在市面主流競品中是比較小的，帶來關斷損耗Eoff也是市面主流產品中非常出色的，優于部分海外競品，特別適用于LLC應用.



Basic™ (BASiC Semiconductor) second generation SiC silicon carbide MOSFET has two main features:

1. Outstanding reliability: Compared with competing products, there is sufficient design margin to ensure device reliability during mass manufacturing.

The breakdown voltage BV value of BASiC Semiconductor's second-generation SiC silicon carbide MOSFET 1200V series is measured to be around 1700V, which is higher than mainstream competing products on the market. The breakdown voltage BV design margin can withstand silicon carbide substrate epitaxial materials and wafers. The swing of the tape-out process can ensure device reliability during mass manufacturing, which is the most critical quality of BASiC Semiconductor’s second-generation SiC silicon carbide MOSFET. BASiC Semiconductor’s second-generation SiC silicon carbide MOSFET The relatively high avalanche tolerance margin also enhances reliability in power electronic system applications.

2. Remarkable device performance: Smaller Crss with the same specifications brings excellent switching performance.

BASiC Semiconductor's second-generation SiC silicon carbide MOSFET reverse transmission capacitor Crss is relatively small among mainstream competing products on the market, and its turn-off loss Eoff is also very good among mainstream products on the market, better than some overseas competing products. , especially suitable for LLC applications, typical applications such as charging pile power module downstream DC-DC applications.



Ciss：輸入電容（Ciss＝Cgd＋Cgs） ⇒柵極-漏極和柵極-源極電容之和：它影響延遲時間；Ciss越大，延遲時間越長。基本™（BASiC Semiconductor）第二代SiC碳化硅MOSFET 優于主流競品。

Crss：反向傳輸電容（Crss＝Cgd） ⇒柵極-漏極電容：Crss越小，漏極電流上升特性越好，這有利于MOSFET的損耗，在開關過程中對切換時間起決定作用，高速驅動需要低Crss。

Coss：輸出電容（Coss＝Cgd＋Cds）⇒柵極-漏極和漏極-源極電容之和：它影響關斷特性和輕載時的損耗。如果Coss較大，關斷dv／dt減小，這有利于噪聲。但輕載時的損耗增加。



傾佳電子（Changer Tech）致力于國產碳化硅（SiC）MOSFET功率器件在電力電子市場的推廣！Changer Tech-Authorized Distributor of BASiC Semiconductor which committed to the promotion of BASiC™ silicon carbide (SiC) MOSFET power devices in the power electronics market!





傾佳電子（Changer Tech）專業分銷的基本™第二代碳化硅SiC MOSFET主要有B2M160120H，B2M160120Z，B2M160120R，B2M080120H,B2M080120Z，B2M080120R，B2M018120H，B2M018120Z，B2M020120Y，B2M065120H，B2M065120Z，B2M065120R，B2M040120H，B2M040120Z，B2M040120R，B2M032120Y，B2M018120Z。適用大功率電力電子裝置的SiC MOSFET模塊，半橋SiC MOSFET模塊，ANPC三電平碳化硅MOSFET模塊，T型三電平模塊，MPPT BOOST SiC MOSFET模塊。

B2M032120Y國產替代英飛凌IMZA120R030M1H，安森美NTH4L030N120M3S以及C3M0032120K。

B2M040120Z國產替代英飛凌IMZA120R040M1H，安森美NTH4L040N120M3S，NTH4L040N120SC1以及C3M0040120K，意法SCT040W120G3-4AG。

B2M020120Y國產替代英飛凌IMZA120R020M1H，安森美NTH4L020N120SC1，NTH4L022N120M3S以及C3M0021120K，意法SCT015W120G3-4AG。

B2M1000170R國產代替英飛凌IMBF170R1K0M1，安森美NTBG1000N170M1以及C2M1000170J。

B2M065120H國產代替安森美NTHL070N120M3S。

B2M065120Z國產代替英飛凌IMZ120R060M1H，安森美NVH4L070N120M3S，C3M0075120K-A，意法SCT070W120G3-4AG。

B2M160120Z國產代替英飛凌AIMZHN120R160M1T，AIMZH120R160M1T

B2M080120Z國產代替英飛凌AIMZHN120R080M1T，AIMZH120R080M1T

B2M080120R國產代替英飛凌IMBG120R078M2H

B2M040120Z國產替代英飛凌AIMZHN120R040M1T，AIMZH120R040M1T

B2M040120R國產替代英飛凌IMBG120R040M2H

B2M018120R國產替代英飛凌IMBG120R022M2H

B2M018120Z國產替代英飛凌AIMZH120R020M1T，AIMZH120R020M1T

B2M065120Z國產替代英飛凌AIMZHN120R060M1T，AIMZH120R060M1T





基本™B2M第二代碳化硅MOSFET器件主要特色：

• 比導通電阻降低40%左右

• Qg降低了60%左右

• 開關損耗降低了約30%

• 降低Coss參數，更適合軟開關

• 降低Crss，及提高Ciss/Crss比值,降低器件在串?dāng)_行為下誤導通風險

• 最大工作結溫175℃• HTRB、 HTGB+、 HTGB-可靠性按結溫Tj=175℃通過測試

• 優化柵氧工藝，提高可靠性

• 高可靠性鈍化工藝

• 優化終端環設計，降低高溫漏電流

• AEC-Q101
